Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler

Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler

capacitive discharge welder

capacitive discharge spot welder

metal products single side spot weler

Place of Origin:

China

Brand Name:

HWASHI

Certification:

CE/CCC/ISO

Model Number:

WL-C-2-40K

Contact Us

Request A Quote
Product Details
Product Name:
Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler
Application:
Welding For All Kinds Of Cookware,metal Products
Size:
900mmX1150mmX1750mm
Weight:
2210kg
Condition:
New
Warranty:
12 Months
Standard:
CE/CCC/ISO
Service Life:
8-10 Years
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiation
Packaging Details
sea worthy wooden package
Delivery Time
7-30 working days after received your payment
Payment Terms
L/C, T/T
Supply Ability
50 sets per month
Product Description

HWASHI TECHNOLOGY Inc.



Website: www.hwashi.com

Thank you & Welcome your Inquiry!



 Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler

SPECIFICATION

 Model

 WL-C15K

 Voltage

 380 V 50HZ

 Power

 20KVA

Energy Storage

8000J

Capacitance

73500uF

 Pressurization

2000kg

 Electrode Stroke

100 mm

 Closure

130-230mm

 Platform Distance

260mm

 Electrode Distance

490-540mm

 Cooling Water

6 Lit/min




DESCRIPTION

Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 0
Capacitor discharge spot welder uses capacitor to store energy and to release instantaneous current. In the meantime, it concentrates large current to pass through a small point and then achieves welding effect (welding process passes through thousands of ampere current within 1/1000 second of time). Therefore, it can minimize the situation that the work piece being oxidized or mechanically deformed due to overheat during the process of welding. The output of the capacitor discharge spot welder that we produce is from 100WS to 18000WS. It is especially suitable for welding metals like red copper, bronze, brass, aluminum, silver and stainless steel, etc. Thus, this type of machine is widely applied to various kinds of industrial production and manufacturing.

Features:
1.Be able to weld 8mm of nonferrous metals like stainless steel, aluminum ,titanium, sliver,etx.
2.Firm welding: no black coating on the welding spots soon polishing process is needed.
3.Equipped with internal power supply voltable stabilizer to ensure constant output voltage and good welding consistency.
4.All the pasts are imported from famous brands with ideal service life and performance.
5.Simple operation, avoid complicated testing program.


APPLICATION
Mainly  applied to industries like low-voltage apparatus, elevator, compressor,automobile manufacturing, kitchen utensils,, glasses, hardware, household appliances,  etc.

Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 1
MATERIAL CONFIGURATION

     Novel structure, special design, good rigidity.Adopt the high definition guidance institution,high staying quality,piston straight pole pressurizing,   high speed welding, pressure steady.
      Projection weld terrace is conveninet to customers to fix tongs,and weld with multiaspect,multi-welding spot.
      Microcomputer constant voltage control system, twice section discharge, precise control of the welding time and welding current, easy to adjust.
      High conduction magnetism silicon sheet steel, secondary whole structure, output current is high, energy-saving and protect environmental .
     Water-transformer,water-controlled silicon, and water-electrode what can improve the use life of equipment.


COMPETITIVE ADVANTAGE

1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.

2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.

3. Genuine Product with Excellent Quality:  12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.

4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.

5. Quick Delivery: Our company provides just-in-time delivery.

6. Prompt Response to Customers: Your satisfaction is the goal we pursue.





          Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 2

Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 3Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 4

Capacitive Spot Welding Machine , Standard Metal Products Single Side Spot Weler 5
