Place of Origin:
Guangzhou Hwashi Technology INC
Brand Name:
Hwashi
Certification:
CE, ISO, GS, CCC
Model Number:
HS-R6-50
Contact Us
Video
Video
HWASHI HS-R6-08 6 Axis Automatic Industrial TIG Welding Robot for Stainless Steel Box 1. Welding system: Panasonic TIG welding machine with automatic wire feeding system. Stable performance. 2. Automatic alarm system: if any problem on the wire feeding or gas supply and so on, the welding robot will alarm and the welding will stop until you clear the alarm. 3. Welding gun system: famous brand TBI welding gun. 4. Welding gun cleaning and wire cutting system: TBI brand.
5. Arc light baffle: cylinder pushes automatic rotation. Use for preventing light pollution during working process.
6. Startcontrol panel system: Manual/Automatic button platform with portable structure. Convenient for operation. 7. Working station positioner: It is designed with two sets of working table. Single table could achieve 3600 rotation which is suitable for multi-angle welding. Two sets of positioner system could achieve 180°rotation through spindle motor. It could achieve alternative use so as to increase efficiency. 8. Work piece clamping system: the cylinders will push and clamp the work piece. Balanced and stable clamping force.
| Items | Parameters | |
| Model | HS-06-50 | |
| Degrees of Freedom | 6 | |
| Driving Method | AC servo driving | |
| Max. Payload | 50kg | |
| Motion Range | 1956mm | |
| Repeated Positioning Accuracy | ±0.05mm | |
| Motion Range | J1Axis | ±178° |
| J2Axis | ＋130°～ -90° | |
| J3Axis | ＋75°～ -200° | |
| J4Axis | ±360° | |
| J5Axis | ±115° | |
| J6Axis | ±360° | |
| Max. Speed | J1Axis | 171°/s |
| J2Axis | 171°/s | |
| J3Axis | 171°/s | |
| J4Axis | 215°/s | |
| J5Axis | 251°/s | |
| J6Axis | 365°/s | |
| Allowed Torque | J4Axis | 196N.m |
| J5Axis | 196N.m | |
| J6Axis | 127N.m | |
| Environment | Temperature | 0℃～55℃ |
| Humidity | 20%～80%(No frost) | |
| Other |
Avoid inflammable, explosive, corrosive gas and liquid; No water, oil, dust; Keep away from noise(plasma) |
|
| Installation Method | Ground installing | |
| Robot Main body | 600kg | |
| Power | Three-phase 380V,50HZ/60HZ | |
| Electric Cabinet Weight | 200kg | |
USED FOR LOCATING THE WORK PIECE ONTO THE AUTOMATIC ROTATE TABLE
Guangdong Hwashi Technology Inc. was established in 2001. The headquarter is located in Hwashi industrial park in Huizhou. Hwashi is a high-tech enterprise specialized in developing, manufacturing and selling of resistance welding machine, automatic welding machine and an industrial robot.
In the past 20 years, Hwashi has obtained more than 50 patents for invention patents, utility model patents, design patents, and software Copyrights. It is the drafting unit of several national standards and industry standards. Hwashi has been awarded "China famous brand", "Guangdong famous brand", "China quality credit enterprise", "world outstanding Chinese businessman association member unit", "Guangdong province science and technology innovation quality management advanced unit", "Guangdong province academician expert enterprise workstation" and many other honorary titles.
For 20 years, Hwashi keeps innovating and follow up with the latest technology in the world. Invest heavily in product development and innovation every year. In cooperation with key universities and national key laboratories and engineering technology centers in new materials and processes, the "medium frequency inverter" technology was first introduced into resistance welding equipment. Help to realize the "unmanned, intelligent" factory, the practice we have been striving for is to create efficient, energy saving, safe and environmentally friendly production environment for customers.
With the trend of intelligent manufacturing in the world, Hwashi has set up a large-scale robot development base of 50,000 square meters in Yichun City, Jiangxi province. Introducing the world's top advanced production and processing equipment in our factory. We have a technical team and high-quality workers including mechanical, electronic, welding, automatic control, electromechanical integration, and management. We are committed to providing customers with efficient automation welding solutions in order to become a leading enterprise in world-class industrial intelligent equipment.
