Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power

Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power

    • Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power
    • Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power
  • Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power

    Product Details:

    Place of Origin: Guangdong China
    Brand Name: HWASHI
    Certification: CCC / CE
    Model Number: WL-B-75K

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: US $4,000-6,000 / Set
    Packaging Details: wooden packing
    Delivery Time: 15 days
    Supply Ability: 50 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Condition: New Electrode Stroke: 100 Mm
    Rated Capacity: 24000 A Discharge Times: Three Sections
    Method: AC Pulse Input Power: 75 KVA
    Pressurization: 1000 Kg Cooling Water: 8 Lit/Min




    Detailed Description
    Low-carbon steel Butt Welding Machine
    Except for the general functions of AC pulse spot welder, this type of machine also possesses the following features: 1. Be able to joint the two ends of work pieces together. To utilize the contact resistance of the two ends on the connecting position to generate high temperature and high heat to achieve welding effect under pressure.

    2. This machine could choose three times of discharging. As for medium carbon steel, this machine possesses the function of preheat and welding anneal and is specially equipped with parallel straight slide to ensure the parallel pressure of forging power of the welding product so as to achieve smoothness and firmness on the joint position.

    3. The power of butt welding machine we produce is from 3KVA to 600KVA. It can be used to weld 10mm of iron wire and metals like stainless steel, steel, copper, etc. Applicable to all kinds of hardware.


    Features
    1. Welding Control System: WD-KD5 Intelligent Microcomputer Controller. The AC pulse spot welder that we produce can be matched with many types of welding controllers.
    2. Silicon Controlled: Adopt the SEMIKRON, IXYS Silicon controlled from West Germany or IR Silicon controlled from United States;
    3. Pneumatic Control System: Adopt large displacement of magnetic valve and gas assembly, sufficient air supply; Adopt the quick exhaust cylinder, quick response, good servo performance.
    4. Welding Transformer: Adopt high purity silicon steel disc refined welding transformer; Good permeability and electrical conductivity; Less consumption of electricity; Be able to weld the metal plates like 8mm+8mm low-carbon steel.

    Application
    Butt welding of wire rod of different size or shape. Also suitable for butt welding of unfolded panel material whose width is within 300mm.

    Samples
    .png



    Thechnical parameters

    Low-carbon steel Butt Welding Machine

    ModelInput VoltageInput PowerSecondary CurrentStroke
    WL-B-16K380V16 KW10000A25 mm
    WL-(S)B-25K380V25 KW12000A25 mm
    WL-B-35K380V35 KW16000A50 mm
    WL-(S)B-50K380V50 KW19500A50 mm
    WL-B-75K380V75 KW24000A50 mm




    Company introduction

    Guangdong Hwashi Technology Inc. was established in 2001. The headquater is located in Hwashi technology industrial area, huiyang, huizhou city. It is a high-tech enterprise speacializing in developing, manufacturing , and seeling of resistance welding machine, automatic weding machine and industrial robot.

    We have professional production team, production line, experienced technical experts who engaged in the industry for more tan 20 years.

    The main products of our company include capacitor discharge spot welder, pneumatic AC pulse spot welder, three-phase secondary rectifying spot welder, medium frequency inverter spot welder, precision micro spot welder and high degree of automatic welding machine.

    Copper Aluminum Tube Butt Welding Machine Automatic Mode 75 KVA Input Power





    Why us
    1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.

    2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.

    3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.

    4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.

    5. Quick Delivery: Our company provides just-in-time delivery.

    6. Prompt Response to Customers: Your satisfaction is the goal we pursue.
