Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width

Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width

    • Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width
    • Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width
    • Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width
  • Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width

    Product Details:

    Place of Origin: Guangdong , China
    Brand Name: HWASHI
    Certification: CE, CCC
    Model Number: WL-AT-PM1200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: US $10,000-30,000 / Set
    Packaging Details: wooden packing
    Delivery Time: 45 days
    Supply Ability: 50 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Grinding Wheel Diameter: 50mm Abrasive Belt Width: 50mm
    Abrasive Belt Rotating Speed: 1400-2800mm/min (adjustable) X Axle Moving Range: ≥1220mm
    Y Axle Moving Range: ≥620mm Z Axle Moving Range: ≥250mm
    A A Sink Edge Grinding / Polishing Sink Welding Machine 50mm Abrasive Belt Widthxle Moving Range: 360 Angle

    HWASHI TECHNOLOGY Inc.



    More details pls contact (Jonny Zhang)

    Whatsapp/Wechat: +86 139 2435 2162

    Skype: szcns_jonny



    Website: www.hwashi.com

    Thank you & Welcome your Inquiry!








    1 DETAILED DESCRIPTION



    HWASHI Italy Design High Efficiency Automatic Stainless Steel Sink Edge Grinding Machine



    This CNC sink grinding special machine utilizes abrasive belt polishing principle. The abrasive belt is driven by electric motor to conduct polishing on the edge of the welded sink. There are two processes for polishing. Firstly, use the coarse abrasive belt to grind the redundant cutting edge and the projection welding spots. Then use the fine abrasive belt to conduct polishing treatment. After these two processes can meet the requirement of sink grinding and polishing treatment. It is designed to use Mitsubishi professional automatic control system. You only need to input the coordinate data of the product and start the machine, the abrasive belt of the machine will conduct grinding and polishing automatically within the track of preset program. The worker only needs to put and take out the sink.



    The product will be fixed on the locating mould. The servo motor will drive the X and Y axle to run within the preset data of program. The machine could store 15 types of grinding models. The grinding wheel will move along with X direction and the max moving range is 1220mm while the max moving range of Y direction is 620mm. The Z axle can conduct moving up and down within the range of max 250mm while the A axle can conduct 360ºrotating under the control of servo motor. This machine is suitable for different directions of product.





    2 FEATURES OF SINK WELDING MACHINE

    HWASHI Italy Design High Efficiency Automatic Stainless Steel Sink Edge Grinding Machine

    • Fully automatic.
    • Utilizes the principle of seam welder with round welding wheel.
    • Save labor cost: only one worker required put the sink into the platform and then take it away when finishing the grinding process
    • Medium frequency inverter power source which is electricity saving.
    • Enhanced function: memorize 16 sets of welding way . If you need more , we could design for you.
    • Adopt the professional automatic control system from Mitsubishi
    • Use the servo motor to drive axis X (locate mould) and axis Y (welding electrode) to operate under the preset procedure of PLC data.





    3 APPLIABLT AREA OF SINK WELDING MACHINE

    HWASHI Italy Design High Efficiency Automatic Stainless Steel Sink Edge Grinding Machine



    Suitable for sink welding within the range of 1600mmx600mm (adjustable according to your needs)



    Sink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt WidthSink Edge Grinding Polishing Sink Welding Machine 50mm Abrasive Belt Width





    4 TECHNICAL PARAMETERS OF SINK WELDING MACHINE

    HWASHI Italy Design High Efficiency Automatic Stainless Steel Sink Edge Grinding Machine



    Model WL-AT-PM1200
    Input Power Three-phase 380V±10% 50Hz
    Rated Capacity 10KVA
    Grinding Wheel Diameter 50mm
    Abrasive Belt Width 50mm
    Abrasive Belt Rotating Speed 1400-2800mm/min (adjustable)
    X Axle Moving Range ≥1220mm
    Y Axle Moving Range ≥620mm
    Z Axle Moving Range ≥250mm
    A Axle Moving Range 360º
    Rated Air Pressure 0.8MPa
    Gas Consumption 1m3/h
