Name: Good Quality Stainless Steel Rocker Arm Bending Equipment Square Curved C Type Crank Arm Table Spot Welding Machine
Brand: GUANGDONG HWASHI TECHNOLOGY INC.
SKU: WL-SF-50/75/100K
Price: 25.00 USD
Availability: InStock

Home > products > Stainless Steel Welding Machine >

Good Quality Stainless Steel Rocker Arm Bending Equipment Square Curved C Type Crank Arm Table Spot Welding Machine

Stainless Steel Rocker Arm Bending Equipment

Crank Arm Table Spot Welding Machine

Place of Origin:

China

Brand Name:

hwashi

Certification:

CE/CCC/ISO

Model Number:

WL-SF-50/75/100K

Request A Quote

Product Details

Model:

WL-SF-50/75/100K

Input Power (V/φ):

380/3

Rated Power (KVA):

50/75/100

Applicable Material:

Stainless Steel, Carbon Steel, Aluminum, Metal

Electrode Force (KG):

250-400

Wleding Thickness (MM):

3.0+3.0

Warranty:

1 Years

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

negotiation

Packaging Details

sea worthy wooden package

Delivery Time

60 working days after received your payment

Payment Terms

L/C, T/T

Supply Ability

50 sets per month

Resistance Multi Point Rocker Arm Table Seamless Desktop Platform Spot Welding Machine for Metal Distribution Cabinet

Get Best Price

Video

HWASHI Flexible Crank Arm Metal Sheet Door Panel C Type Crank Arm Table Spot Welding Machine Sheet Metal Spot Welder

Get Best Price

Video

Hwashi CNC Seven Axis Double Heads Auotmaitc Spot Welding Machine for Door Tube Frame

Get Best Price

Video

Hwashi Door Panel Multi Head Spot Welding Machine

Get Best Price

+86-13380655800

export_trade@hwashi.com

86-752-3528326

Contact Now

Product Description

Good Quality Stainless Steel Rocker Arm Bending Equipment Square Curved C Type Crank Arm Table Spot Welding Machine

The Sheet Metal Reinforcement Welding Machine is a high-performance industrial equipment designed for seamless welding of metal sheets (e.g., steel, aluminum, stainless steel) in structural reinforcement applications. Combining advanced arc welding technology with automated precision, it ensures robust joint strength, minimal deformation, and superior durability for heavy-duty fabrication.


Intelligent welding control system Intelligent Touch Screen Controller Input and read welding parameters. The welding conditions can be easily set using the touch panel system.You can save the different welding parameters for different material and thickness. So you can recall the welding program easily	Welding platform Flat big copper table for welding various sheet metal door panels. If the workpiece can be placed on the table-type electrode, it can be welded without the use of auxiliary personnel. The welding gun move freely, allowing easy access to the desired welding point by one person.

Standard Welding Electrode Welding can be done efficiently by changing the electrode tip according to the type and size of product. It can also weld nut, or screws, etc.	Easy Set up and Operation. Comfortable working position: There is no need to hold the workpiece during welding; Pressurization is also automatic, greatly reducing the physical burden on the operator.

Key Features

1.Heavy-Duty Welding Capacity

Supports MIG/MAG, TIG, and Spot Welding modes for versatile sheet metal joining.
Welds materials up to 8mm thickness with stable arc control.

2.Intelligent Power System

Inverter-based power supply with 220V/380V dual voltage compatibility.
Energy-saving design reduces power consumption by 20% compared to conventional models.

3.Precision Control

Digital LCD interface with programmable parameters (current: 50-350A, voltage: 15-30V).
Auto-calibration for wire feed speed and gas flow (argon/CO₂).

Table Spot Welding Machine
1. The movement patterns of crank arm mobile flat plate spot welder can be chosen as manual or CNC automatic mobile type.
2. The structure of manual mobile method is simple. It is convenient, flexible to move manually and the locating of welding spot is simple. Good applicability to complicated products.
3. Automatic mobile method adopts the coding servo motor, which is equipped with precision-machined good quality of slide rail, ball screw and automatic testing system in order to complete the electrode automatic movement.
4. Automatic device adopts the axis X, Y of mobile working table, utilizing the PLC to store setting mobile program. Simple and convenient setting.
5. Adopt direct single-point welding method. The lower electrode is designed as complete flat, which is suitable for welding of flat plate with multiple welding spots on the surface and be able to guarantee both the smoothness of surface and the consistency of welding spots.

Specification

Model	WL-SF-50/75/100K
Input Power (V/φ)	380/3
Rated Power (KVA)	50/75/100
Applicable Material	Stainless Steel, Carbon steel, Aluminum, Metal
Electrode Force (KG)	250-400
Wleding Thickness (MM)	3.0+3.0
Warranty	1 years

Application and samples

We can provide customized service for you. Our engineers will discuss the specific welding requirement with you and come out with the suitable technical proposal based on your samples or drawings.

Applicable industries:

Various industries such as chassis and cabinets, elevators, electrical cabinets, automobiles, steel and wood furniture, kitchen appliances, etc.

Factory & Certificate

HWASHI : 22 years+ experience welding solutions expert

Guangdong Hwashi Technology Inc. which was established in 2001, is located in Huizhou, Guangdong province in China. We are the high-tech enterprise which is specialized in developing, manufacturing, and selling of resistance welding machine, automatic welding machine and industrial robot station. We have total two manufacturing plants covering an area about 60000 square meters.There are about 200 staffs in Hwashi, and among which there are more than 20 mechanical and electrical engineers. Most of our engineers got more than 10 years experience in welding industry. Until now, we got more than 70 patents regarding the welding machine projects. Our machines have been exported to more than 70 counrties in the world. And we have local distributor in Russia, Turkey, Romania, Saudi Arabia, Malaysia, Indonesia, India, and USA, etc. who will provide you professional pre-sales and after-sales service in local.
