Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology

Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology

Multiple-Head Synchronous Wire Mesh Spot Welding Machine

Adaptive Welding Technology Automatic Wire Welder

Automatic Wire Filling Multiple Head Welding Machine

Place of Origin:

CHINA

Brand Name:

HWASHI

Certification:

CE

Model Number:

WL-SQ-150K*2

Contact Us

Request A Quote
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology
Product Details
Product Name:
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine For Oven Cooking Racks
Dimension(L*W*H):
According To Your Product
Weight:
According To Your Product
Core Components:
PLC, Engine, Motor
Warranty:
1 Year
Welding Power Source:
AC / MF DC
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Sea worthy wooden package or PVC Film for FCL
Delivery Time
30 - 45 working days after received your payment
Payment Terms
L/C,T/T
Supply Ability
50 sets per month
RELATED PRODUCTS
Good price Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology online Video

Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology

Get Best Price
Good price High Speed PLC Control Automatic Wire Tube Condenser Production Line Machine and Welding Bending Machine online Video

High Speed PLC Control Automatic Wire Tube Condenser Production Line Machine and Welding Bending Machine

Get Best Price
Good price HWASHI Automatic Gantry Style Wire Mesh Welding Machine with 10 Welding Heads 40000A Output Current and Automatic Wire Filling System online Video

HWASHI Automatic Gantry Style Wire Mesh Welding Machine with 10 Welding Heads 40000A Output Current and Automatic Wire Filling System

Get Best Price
Good price Automatic Wire Mesh Welding Machine with 200mm/S Maximum Wiring Speed, 2D Wire Handle Bending, and 1 Year Warranty online Video

Automatic Wire Mesh Welding Machine with 200mm/S Maximum Wiring Speed, 2D Wire Handle Bending, and 1 Year Warranty

Get Best Price
CONTACT US
+86-13380655800
export_trade@hwashi.com
86-752-3528326
Contact Now
Product Description
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine for Shopping Cart
The Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine is a high-performance, purpose-built industrial equipment engineered exclusively for the mass production of shopping cart wire mesh components. Integrating advanced automation technology and precision welding mechanics, this machine delivers consistent weld quality, high throughput, and reliable operation to streamline the assembly of shopping cart frames, baskets, and mesh partitions.
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 0
Key Features
  • Multiple-Head Synchronous Welding: Equipped with 2-8 independent, adjustable welding heads that work synchronously to reduce production time by 40-60% compared to single-head machines, ideal for large-batch shopping cart manufacturing.
  • Adaptive Welding Technology: Intelligent current control system automatically adjusts welding current, pressure, and time based on wire diameter and mesh layer thickness, ensuring each weld meets industrial load-bearing standards (supports up to 50 kg of static load).
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 1
Intelligent Welding Control System
Automatic welding by inputting coordinate data of welding position, welding current and other parameters
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 2
Welding Heads and Fixtures
Processing and design according to the drawings of each wire shelf product (customized)
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 3
Automatic Wire Filling System
Put precut straight wires into the hopper, and the system automatically fills wires into the fixture to increase efficiency and reduce labor
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 4
Automatic Double-layer Feeder
While one fixture is welding, the wire filling system loads wires onto the other fixture simultaneously, automatically exchanging fixtures when welding completes
Production Line Machines
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 5
Wire Flattening and Cutting Machine
Processes round wire into flat wire, automatically feeding round wire and cutting to required length. Typically processes 8mm wire coil into 12x3mm flat wire strips.
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 6
High Speed Wire Straightening and Cutting Machine
Produces batch quantities of 2mm to 4mm wires at nearly 5 times the speed of normal wire cutting machines, increasing production rate and reducing labor costs.
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 7
Wire Frame Bending Machine
Bends flat or round wires into square-shaped wire frames, capable of bending multiple wires simultaneously to increase production rate.
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 8
Wire Frame Butt Welding Machine
Number of welding heads depends on mesh welding width. Different welding heads can be set with individual welding programs and currents respectively.
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 9
Wire Frame Double T-Butt Machine
Welds cross bars of wire shelf to wire frame. Double head design increases production rate with easy operation. Automatic moving and welding applications available.
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 10
Wire Edge Trimming Machine
Trims wire edges from wire frame after welding to create clean, smooth surfaces.
Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 11
2D Wire Handle Bending Machine
Bends wire handles for 2-6mm wire. Capable of bending any shape without changing molds.
 Hwashi Automatic Multiple Head Wire Mesh Spot Welding Machine with Synchronous Welding and Adaptive Technology 12
3D Wire Bending Machine
Bends wire into 3D shapes for 2-6mm or 3-8mm wire. Capable of bending any 3D shape without changing molds.
