Name: CNC Servo IBC Frame Welding Center with 0.01mm Positioning Accuracy 150 Weld Points/Min and 70-90 Frames Per Shift
Brand: GUANGDONG HWASHI TECHNOLOGY INC.
SKU: IBC-CNC-150
Price: 55,000.00 USD
Availability: InStock

Home > products > IBC Welding Machine >

CNC Servo IBC Frame Welding Center with 0.01mm Positioning Accuracy 150 Weld Points/Min and 70-90 Frames Per Shift

CNC Servo 0.01mm Positioning Accuracy

150 Weld Points Per Minute Output

Programmable 50-Recipe Frame Welding

Place of Origin:

Guangdong, China

Brand Name:

WNRLN

Certification:

ISO 9001:2015, CE

Model Number:

IBC-CNC-150

Request A Quote

Product Details

Recipe Memory:

50 Programmable Frame Configurations

Cooling System:

Closed-loop Chiller, 18L/min, ±1°C Stability

Control System:

Fanuc CNC With 15-inch Industrial Touchscreen

Frame Dimensions:

Up To 1400x1200mm

Production Capacity:

70-90 Frames / 8-hour Shift

Electrode Force:

500-3000N, Servo-controlled With 1N Resolution

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

USD 45000-65000 / Set

Packaging Details

Export-grade plywood case with climate-controlled sealing for servo drives and CNC controller, vibration-dampening mounts

Delivery Time

35-45 working days

Payment Terms

T/T,L/C

Supply Ability

8 Sets per Month

Versatile IBC Cage Frame Combo Welding Machine Dual-Mode 60 Points/Min 40-50 Units Per Shift Multi-Purpose

Get Best Price

Video

Pneumatic High-Efficiency IBC Mesh Welding System 75 Points/Min 100-115 Panels Per Shift Brazilian Market Proven

Get Best Price

Video

Entry-Level Automatic IBC Cage Production Cell 55 Points/Min Modular 30-40 Cages Per Shift Affordable Starter Solution

Get Best Price

Video

CNC Servo IBC Frame Welding Center with 0.01mm Positioning Accuracy 150 Weld Points/Min and 70-90 Frames Per Shift

Get Best Price

+86-13380655800

export_trade@hwashi.com

86-752-3528326

Contact Now

Product Description

CNC Servo IBC Frame Welding Center

⚡ CNC Precision Meets High-Volume Welding

The IBC-CNC-150 combines Fanuc CNC control with servo-driven electrode positioning to deliver 0.01mm positioning accuracy at 150 weld points per minute. Each welding point uses servo-controlled electrode force with 1N resolution, ensuring identical weld quality across every cage produced. Output reaches 70-90 precision-welded frames per 8-hour shift. A repeat customer supplying IBC cages to the European pharmaceutical sector operates 4 units, achieving zero customer rejects over 18 months due to CNC-level consistency. The 50-recipe memory supports instant product changeovers for mixed-model production.

Key Efficiency Features

Fanuc CNC 3-Axis Control	0.01mm X-Y positioning, servo-driven Z-axis electrode force with 1N resolution closed-loop
50-Recipe Program Memory	Store complete weld programs including position, current, force, and time for instant recall
Servo Electrode Force Control	500-3000N programmable force with real-time feedback — weld consistency within ±2%
Weld Quality Monitoring	Real-time current, voltage, force, and displacement graphing with upper/lower limit alarms
15-Inch Industrial Touchscreen	G-code style programming interface with graphical weld path preview and simulation

Production Data (Verified at Customer Sites)

Customer Rejects Over 18 Months

0.01mm

Positioning Accuracy

4 Units

Repeat Deployment (Pharma Supply)

Why Customers Reorder

✅ Zero rejects in 18 months — CNC consistency satisfies European pharma quality standards
✅ 50-recipe instant changeover — mixed IBC frame production without downtime
✅ Real-time quality monitoring — full traceability with weld data export for customer audits
✅ ±2% weld consistency — servo force control maintains identical nugget diameter across production

📦 Package Includes: CNC welding center with 3-axis servo system, Fanuc CNC controller, 15-inch industrial touchscreen, servo electrode force system, closed-loop water chiller, weld quality monitoring software, spare electrode set (60 tips), tool kit, comprehensive English documentation, remote diagnostic modem.
