Pneumatic High-Efficiency IBC Mesh Welding System 75 Points/Min 100-115 Panels Per Shift Brazilian Market Proven

Pneumatic IBC mesh welding system

High-efficiency IBC welding machine

Brazilian market IBC welder

Place of Origin:

Guangdong, China

Brand Name:

WNRLN

Certification:

ISO 9001:2015, CE, INMETRO

Request A Quote

Product Details

Welding Speed:

75 Mesh Intersections/min

Production Capacity:

100-115 Panels / 8-hour Shift

Electrode Array:

12-electrode Pneumatic Array, Individually Adjustable

Control System:

PLC With 7-inch HMI, Tropicalized PCB Coating

Panel Dimensions:

Up To 1200x1150mm

Wire Diameter Range:

3.0-6.0mm

Mesh Opening Sizes:

50x50mm To 100x100mm

Power Rating:

110 KVA, 380/440V 3-phase 60Hz (Brazil Standard)

Wire Feeding:

3-line Motorized Decoiler With Hardened Straightener Rollers

Cooling System:

High-flow Chiller, 22L/min, Tropical Ambient Rated (45°C)

Cycle Time:

25-35 Seconds Per Panel

Machine Dimensions:

4500x2600x1850mm

Total Weight:

2800 Kg

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

USD 16000-23000 / Set

Packaging Details

Heavy-duty export-grade plywood case with tropicalized protection (anti-fungus treatment for humid climates)

Delivery Time

20-30 working days

Payment Terms

T/T,L/C,Western Union

Supply Ability

22 Sets per Month

Versatile IBC Cage Frame Combo Welding Machine Dual-Mode 60 Points/Min 40-50 Units Per Shift Multi-Purpose

Get Best Price

Video

Pneumatic High-Efficiency IBC Mesh Welding System 75 Points/Min 100-115 Panels Per Shift Brazilian Market Proven

Get Best Price

Video

Entry-Level Automatic IBC Cage Production Cell 55 Points/Min Modular 30-40 Cages Per Shift Affordable Starter Solution

Get Best Price

Video

CNC Servo IBC Frame Welding Center with 0.01mm Positioning Accuracy 150 Weld Points/Min and 70-90 Frames Per Shift

Get Best Price

+86-13380655800

export_trade@hwashi.com

86-752-3528326

Contact Now

Product Description

Pneumatic High-Efficiency IBC Mesh Welding System

💰 Built for the Real World — Where Reliability Creates Real Value

The machine is engineered specifically for the demanding production environments of Brazil, Turkey, and Southern Europe. Its robust pneumatic-mechanical design delivers 75 weld intersections per minute producing 100-115 mesh panels per 8-hour shift. Unlike inverter-based systems requiring specialized electronics technicians, the MPW-75B uses standard pneumatic and electrical components serviceable by any industrial maintenance team. Brazilian customer in Joinville (Santa Catarina) operates 4 MPW-75B units in a high-humidity coastal facility, reporting 97.8% uptime over 2 years with only scheduled maintenance — zero unplanned downtime. Turkish distributor data shows 12 units placed in Anatolian factories with an average 3.2-month repeat order cycle as customers expand production. The tropicalized design (anti-fungus PCB coating, 45°C chiller rating, 440V/60Hz native) eliminates the reliability problems that plague non-hardened equipment in humid and hot climates.

Key Value Features

12-Electrode Pneumatic Array	Each electrode individually adjustable — no electronic calibration needed after setup
Tropicalized Full Protection	Anti-fungus conformal coating on all PCBs, stainless steel fasteners, 45°C chiller rating
440V/60Hz Native (Brazil)	Pre-configured for Brazilian industrial power grid — no step-down transformer required
Hardened Straightener Rollers	Induction-hardened to HRC 58-62 — withstands abrasive wire conditions common in Brazilian steel
INMETRO Certified	Full Brazilian INMETRO compliance for electrical safety — no customs or operational barriers

Value Data (Customer-Verified)

97.8%

Uptime Over 2 Years (Joinville, BR)

Units in Anatolian Factories (Turkey)

3.2 mo

Average Repeat Order Cycle

Regional Market Advantages

🇧🇷 Brazil: Purpose-built for Brazilian industrial conditions — 440V/60Hz, tropicalized, INMETRO certified, local stock in Joinville SC
🇹🇷 Turkey: Proven across Anatolian manufacturing — Kayseri, Konya, and Gaziantep installations with local service partner
🇪🇺 Southern Europe: Ideal for Spain, Portugal, and Greece — CE certified with 400V/50Hz option, robust design for warm climates

📦 Package Includes: 12-electrode pneumatic mesh welding unit, 3-line motorized decoiler with hardened straightener rollers, tropicalized PLC with 7-inch HMI, high-flow tropical-rated water chiller (45°C ambient), stainless steel hardware kit, spare electrode set (24 tips), INMETRO and CE compliance documentation, English/Portuguese/Turkish operation and maintenance manual.
