HW-AM1700V Vineyard Trellis Mesh Welding Machine 1700mm Galvanized Wire Panel Builder

Vineyard Trellis Panel Welding Machine

The HW-AM1700V is a 1700mm galvanized wire panel welding machine for vineyard and orchard trellis systems built for Chilean, Argentine, Mexican and Californian vineyard suppliers building trellis panels for new plantings. It combines a rigid stress-relieved frame, a 150 kVA medium frequency DC welding transformer and a PLC touchscreen HMI, so a single operator can hold consistent nugget strength across a full shift.

Why Buyers in the Americas Choose This Model

• Panel heights matched to single wire and double wire trellis systems used across American vineyards.
• Low heat weld schedule preserves the galvanized coating for a long outdoor service life.
• High tensile wire handling without wire slip or distortion at the weld zone.
• Optional tension wire guides and anchor loop fixtures prepared to your planting plan.
• Documentation and HMI delivered in Spanish for Latin American operators on request.

Built-In Customization Capability

• Panel height, post spacing and wire pitch built to your vineyard layout drawings.
• Optional end post reinforcement and tension anchor welding fixtures.
• Custom bundling for compact shipping to remote vineyard sites.
• Machine can be configured for 380V 50Hz and 440V 60Hz destinations.

Technical Specifications

Typical Applications

• Vineyard trellis and training panels
• Orchard support and espalier frames
• Hops and berry support mesh
• Agricultural windbreak panels

Custom Order Workflow

1. Send us your mesh drawing, panel size, wire diameter and target output per shift.
2. Our engineers return a tooling layout, cycle-time estimate and a fixed quotation within 48 hours.
3. Confirm the layout, then we machine the electrodes, fixtures and wire feeding rails for your mesh only.
4. Pre-acceptance video test with your wire sample, then seaworthy packing and container loading plan.

Delivery, Compliance and Service

Machines are wired to the destination grid on request: 480V/60Hz three phase for the United States and Canada, 440V/60Hz for Chile and Peru, 220V/60Hz single or three phase for Mexico, Colombia and Brazil. Control cabinets ship with English and Spanish HMI screens, a full electrical schematic and a spare-electrode kit. Certification documents for CE, CCC and ISO 9001:2015 are supplied with the shipping documents, and 24-hour remote technical support is available in English and Spanish.

Ask for a customized proposal today and we will match the machine, tooling and packing to your exact panel program.
